Bluetooth Remote (RC-01)
Everything related to pairing, configuring, and using the Accutroll RC-01 Bluetooth Remote.
Quick Links
Overview
The RC-01 is a compact Bluetooth remote that provides wireless control of the TCM—including Idle/Resume, throttle adjustments, cruise control activation, and user-configurable macros. It pairs to your phone, not the TCM; the app translates BLE commands over Wi-Fi. Connect the remote from the device list (green Bluetooth icon) before opening the TCM UI, and keep the app in the foreground. Documentation in this section covers pairing workflows, configuration, and best practices for on-the-water use.
User buttons 1, 2, and 3 each support single-click and double-click assignments. Each slot can be set to a single action (instant preset), a one-shot macro (a sequence that runs once), or a repeating macro (a sequence that loops until interrupted). See Configure for details.
Power & Battery
The RC-01 is powered by a CR2032 coin cell battery, which typically lasts 1–2 seasons of normal use.
Sleep & Wake
To conserve battery, the remote automatically enters sleep mode after 2 hours of inactivity. To wake it, press any button. The remote will then advertise for Bluetooth connection for 30 seconds, indicated by a blinking blue LED behind the Idle/Resume button. If no connection is established within that window, the remote returns to sleep.
RC-01 Button Overview
Use the diagram below to identify each button on the RC-01 remote.
 | Speed Lock |
 | Idle/Resume |
 | Plus |
 | Minus |
 | User Button 1 |
 | User Button 2 |
 | User Button 3 |
| Button | Identification | Description |
|---|---|---|
| Speed Lock | Single Click: Locks the current speed and enables cruise control. Double Click: Deactivates cruise control. |
| Idle/Resume | Single Click: Sets throttle to IDLE (0%). Double Click: Resumes the previous throttle setting. |
| Plus | Single Click: Increases throttle percentage or cruise speed by 1% (default). Double Click: Increases throttle percentage or cruise speed by 5% (default). |
| Minus | Single Click: Decreases throttle percentage or cruise speed by 1% (default). Double Click: Decreases throttle percentage or cruise speed by 5% (default). |
| User Button 1 | Single Click: Triggers the assigned single-click user slot. Double Click: Triggers the assigned double-click user slot. |
| User Button 2 | Single Click: Triggers the assigned single-click user slot. Double Click: Triggers the assigned double-click user slot. |
| User Button 3 | Single Click: Triggers the assigned single-click user slot. Double Click: Triggers the assigned double-click user slot. |
