Bluetooth Remote (RC-01)
Everything related to pairing, configuring, and using the Accutroll RC-01 Bluetooth Remote.
Quick Links
Overview
The RC-01 is a compact Bluetooth remote that provides wireless control of the TCM—including Idle/Resume, throttle adjustments, cruise control activation, and user-configurable macros. Documentation in this section covers pairing workflows, configuration, and best practices for on-the-water use.
User buttons 1, 2, and 3 each support single-click and double-click assignments. Each slot can be set to a single action (instant preset), a one-shot macro (a sequence that runs once), or a repeating macro (a sequence that loops until interrupted). See Configure for details.
Power & Battery
The RC-01 is powered by a CR2032 coin cell battery, which typically lasts 1–2 seasons of normal use.
Sleep & Wake
To conserve battery, the remote automatically enters sleep mode after 2 hours of inactivity. To wake it, press any button. The remote will then advertise for Bluetooth connection for 30 seconds, indicated by a blinking blue LED behind the Idle/Resume button. If no connection is established within that window, the remote returns to sleep.
RC-01 Button Overview
Use the diagram below to identify each button on the RC-01 remote.
 | Speed Lock |
 | Idle/Resume |
 | Plus |
 | Minus |
 | User Button 1 |
 | User Button 2 |
 | User Button 3 |
| Button | Identification | Description |
|---|---|---|
| Speed Lock | Single Click: Locks the current speed and enables cruise control. Double Click: Deactivates cruise control. |
| Idle/Resume | Single Click: Sets throttle to IDLE (0%). Double Click: Resumes the previous throttle setting. |
| Plus | Single Click: Increases throttle percentage or cruise speed by 1% (default). Double Click: Increases throttle percentage or cruise speed by 5% (default). |
| Minus | Single Click: Decreases throttle percentage or cruise speed by 1% (default). Double Click: Decreases throttle percentage or cruise speed by 5% (default). |
| User Button 1 | Single Click: Triggers the assigned single-click user slot. Double Click: Triggers the assigned double-click user slot. |
| User Button 2 | Single Click: Triggers the assigned single-click user slot. Double Click: Triggers the assigned double-click user slot. |
| User Button 3 | Single Click: Triggers the assigned single-click user slot. Double Click: Triggers the assigned double-click user slot. |
